● Load Capacity: 8tons
● Lifting Height: 20.5m
● Accept OEM and ODM Customization
● 24/7 Online Customer Support
● Climbing Ability: 20°(36%)
● T/T Payment terms:30% deposit, 70% T/T before shipment
Spider cranes are a new type of lifting equipment characterized by their high efficiency, flexibility, and strong load capacity, and they are widely used in various fields and industries.
1. High Flexibility: Spider cranes can without problems adapt to a number of complicated environments and are appropriate for lifting operations in limited spaces.
2. Strong Load Capacity: Spider cranes now not solely have remarkable flexibility but additionally possess robust load capacity, permitting them to safely and efficiently whole a range of complex lifting tasks.
3. Easy Operation: Spider cranes can be operated wirelessly or manually, with quick working speeds and easy operation.
4. Exquisite Design: Spider cranes characteristic a miniature layout with a small quantity and mild self-weight, making them handy for working in tight spaces, thereby increasing work efficiency and safety.
Technical Parameters
| Model No. | ESC-15 | ESC-20 | ESC-30 | ESC-50 | ESC-80 | ESC-100 | ESC-120 | ESC-160 | |
| Load Capacity | 1.5tons | 2 tons | 3 tons | 5 tons | 8 tons | 10 tons | 12 ton | 16 tons | |
| Lifting Height | 5.8m | 6.8m | 10.05m | 16m | 18m | 21m | 24.5m | 24.5m | |
| Max Operating Radius | 6m×0.4t | 6m×0.4t | 8.6m×0.4t | 15.3m×0.4t | 16.5m×0.35t | 20m×0.2t | 23m×0.2t | 23m×0.2t | |
| Walking device | Walking Mode | Hydraulic motor drive, two speed | |||||||
| Walking Speed | 0-2.5km/h | 0-2.5km/h | 0-2.5km/h | 0-5.5km/h | 0-5.5km/h | 0-5.5km/h | 0-5.5km/h | 0-5.5km/h | |
| Climbing Ability | 20°(36%) | ||||||||
| Engine | Start Mode | Electric start | |||||||
| Startup Tempt. | -5°C~40°C | ||||||||
| Engine | AC Electric + Diesel Dual Power | ||||||||
| Battery Capacity | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | |
| Weight(KG) | 1200kg | 1500kg | 2600kg | 6300kg | 7600kg | 8200kg | 11500kg | 13500kg | |
| Vehicle Size(e( L*W*H) | 2.1*0.6*1.4m | 2.2* 0.95*1.65m | 3.4*0.95*1.65m | 4.5 *1.4 * 2.1m | 4.95*1.6*2.25m | 5.5*1.6*2.25m | 5.7*1.8* 2.4m | 6.5*2*2.4m | |
| 20ft Container Loading Qty | 5 sets | 3 sets | 2 sets | 1 set | 1 set | 1set | 1 set | 1set | |
A: We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.
A: Yes, offer us necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
A: Yes, we support mass production. We can support customization (one piece is enough), but we can’t provide free samples.
A: Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish Other customizable options
EOM’s team is online 24 hours a day to answer your questions. Reach out immediately to find the perfect spider cranes for your business.
